KOOLUX KL6S Electric Folding Bike

Specifications

Specification	Details
Body Material	Aluminum alloy
Color	Black
Unfolding Size	1780mm*790mm*1118mm
Folding Size	960*470*890mm
Hub Form	Integrated wheel
Wheel Size	20 inches
Package Size	1450mm*280mm*790mm
Gross/Net Weight	36kgs/30.5kgs (79.37lbs/67.24lbs)
Maximum Load	120kgs (264.55lbs)
Maximum Speed	25km/h (15mph)
Mileage	70km-120km (affected by load, temperature, and road conditions)
Maximum Climbing Angle	25 degrees
Proper Temperature	-10~45°C
Waterproof Level	IP54
Battery Type	18650 lithium-ion power battery
Battery Capacity	15.6Ah (748.8Wh)
Battery Rated Voltage	48V
Motor Rated Power	0.25kW
Motor Form	Assist mode
Motor Type	20 inch/high-speed gear/Integrated wheel brushless motor
Motor Rated No-Load Speed	400±10r/min
Charger Output	54.6V 3.0A
Charger Input	100-240V 50/60Hz 3.0A
Undervoltage Protection Value	40.5V
Overcurrent Protection Value	21A±1A
Charging Time	7-8 hours
Instrument Display	Multifunctional LCD screen
Front Lighting	YES
Braking Method	Front disc brake + Rear disc brake
Pneumatic Tires	Tire: 20*4.0 Air Valve: AV
Front Fork	Shock fork
Gear	7 Speeds transmission

Geometry

• A Total length: 168 cm
• B Handlebar height: 115-128 cm
• C Wheelbase: 115 cm
• D Standover height: 83-106 cm
• E Top tube length: 60 cm
• F Wheel diameter: 20”
• G Handlebar width: 58 cm
• Folded size: 96*38*75 cm
• Driver size: 165-195 cm

Key Features

• Efficient Powerful Electric Motor: 250W 48V motor with 25-degree slope capability and a detachable 15.6Ah battery for 70-120km range.
• Intimate Design: Aluminum alloy frame, foldable for easy transport, comfortable breathable seat, and easy-to-read LCD display.
• Upgraded Shifting: 3 riding modes: pedal assist, pure electric, and normal pedal mode with 7-speed Shimano transmission.
• Advanced Safety Features: Hydraulic braking system, bright LED lights, and a sturdy frame for rider safety.
• Comfort Shock Absorption: Front suspension and large-capacity low-pressure tires for additional shock absorption on rough terrain.
• Professional 20” Fat Ebike: Features Kenda 4.0-size tires for durability and stability in all terrains.

What's in the Package?

• Electric Bike × 1
• Charger × 1
• Manual × 1
• Throttle Included

Note

The bike is fully compliant with electric bicycle regulations for public streets. The optimal height for users is between 162cm and 190cm, with a seat height of 80-96 cm.
